Uflex Up28r Rear Mount Helm 1.7 Cu. 3/4" Tapered Stainless Steel Shaft
Special Price
$682.74
Regular Price
$1,010.16
In stock
SKU
UFLUP28R
Free Ground Shipping*
Condition: New
UFLEX UP28R REAR MOUNT HELM 17 CU 34 TAPERED SS SHAFTUP28R Rear Mount Helm 17 cu 34 Tapered Stainless Steel ShaftFeaturesAvailable in four different displacement sizesCompact designBall bearing piston raceBuiltin lock valve for positive rudd...
Customer Questions
Uflex Up28r Rear Mount Helm 1.7 Cu. 3/4" Tapered Stainless Steel Shaft
UP28R Rear Mount Helm 1.7 cu. 3/4" Tapered Stainless Steel Shaft
Features:
- Available in four different displacement sizes
- Compact design
- Ball bearing piston race
- Built-in lock valve for positive rudder lock
- Integral relief valve for over-pressure protection
- 3/4” tapered stainless steel shaft
- Easily accessible lock valve and shaft seal for replacement
- Cast iron cylinder rotor for greater durability and longer life
- 1/4" NPT fitting for 3/8" tube
- Includes 90° adjustable fittings for 3/8” tube and white bezel
- UP45R pump is ideal for double cylinder outboard applications
- UP45 pump is available also for inboard application
- X68 (optional) - 40894Z Chrome bezel
- KITF (optional) - 39664Y Remote fill adapter
Specifications:
- Mounting: Retro-cruscotto
- Displacement/Revolution: 28 cc-1.7 cu in
- # of Pistons: 5
- Relief Valve Setting: 70 Bar - 1000 PSI
- Maximum Wheel Diameter: 710mm - 28"
- Weight: 5kg - 11 lbs.
Manufacturer Part Number: UP28R
| Special Shipping Message | Free Ground Shipping* |
|---|---|
| Manufacturer Part Number: | UP28R |
