Blue Sea 7085 70 Amp Circuit Breaker Panel Mount 285 Series
Special Price
$55.10
Regular Price
$89.99
In stock
SKU
BLU7085
Free Ground Shipping*
Condition: New
BLUE SEA 7085 70 AMP CIRCUIT BREAKER PANEL MOUNT 285 SERIES285Series Circuit Breaker Panel Mount 60A Drop in replacement for 185Series Circuit Breakers Visible reset lever shows open condition Trip Free cannot be held closed after trip...
Customer Questions
Blue Sea 7085 70 Amp Circuit Breaker Panel Mount 285 Series
285-Series Thermal Circuit Breaker Panel Mount - 70APart#7085
- Drop in replacement for 185-Series Circuit Breakers
- Visible reset lever shows open condition
- Ignition protected - Safe for installation aboard gasoline powered boats
- Meets SAE J1171 external ignition protection requirements
- Weather Resistant
- Combines switching and circuit breaker function into one unit
- "Trip Free" - cannot be held closed after trip
* Do not use for direct control of high inrush loads such as motor starting.
Specifications
Interrupt Rating 3,000A @ 48V DC*
Maximum Voltage Rating 48 Volts DC
Operating Temperature Range -40°C to 85°C
Circuit Breaker Type Thermally Responsive Bi-metal blade
Circuit Breaker Class Type III - Switchable / Manual Reset - Trip Free
Terminal Stud Size M6 (accepts 1/4" Ring Terminal)
Terminal Stud Torque 50 in-lb
Mounting Holes Accept 1/4" (M6) screw
Weight Lb (Kg) 0.33 lb (0.15 kg)
* AIC ratings achieved using SAE J1625
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
Manufacturer Part Number: 7085
| Special Shipping Message | Free Ground Shipping* |
|---|---|
| Manufacturer Part Number: | 7085 |
